Oculus-C1 White
Oculus-C1 White is a surface-mounted luminaire from the Oculus range by Atolux. The luminaire is surface-mounted, directed downward and fitted with Lens. The range is intended for offices, museums, healthcare, education, public spaces, leisure venues and retail.
Sales can help with quote requests and project-specific questions.
Back to productsDescription
Oculus-C1 White is a surface-mounted luminaire from the Oculus range by Atolux. The luminaire is surface-mounted, directed downward and fitted with Lens. The range is intended for offices, museums, healthcare, education, public spaces, leisure venues and retail.
With the Oculus-C1 White you choose architectural lighting that unites design and light quality within the Oculus family. Engineered for kantoren, museums, healthcare, education, public spaces, vrijetijdssector, retail, it integrates cleanly into the design and delivers comfortable, considered light. Thoughtful detailing and a high-quality finish make it a lasting choice that elevates your project.
LDT / Photometrics downloads
- LDT / Photometrics downloads
All LDT and photometrics downloads are managed centrally per product family.
Specification text
Oculus-C1 White is a surface-mounted luminaire from the Oculus range by Atolux. The luminaire is surface-mounted, directed downward and fitted with Lens. The range is intended for offices, museums, healthcare, education, public spaces, leisure venues and retail.
Specifications
- Category
- Surface-mounted luminaires
- Brand
- Atolux
- Mounting type
- Surface-mounted
- Application type
- Kantoren, Musea, Zorg, Education, Public spaces, Vrijetijdssector, Retail
- Dimensions
- 70x80mm
- Material
- Aluminium (behuizing)
- Optics
- Lens
- IP class
- IP20 (boven) / IP20 (onder)
- Colour rendering (CRI)
- CRI90
- Colour temperature (CCT)
- 3000K, 4000K
- Dimming / control
- aan/uit, DALI-2
- Voltage / frequency
- 220-240V, 50 / 60Hz
- Efficiency
- 80
- Photobiological safety
- IEC 62471: RG1 (low risk)
- Insulation class
- Class II
- Power factor
- >0.9
- Ambient temperature
- -20°C / +40°C
- Colour
- White
- Shape
- Round
- Orientation
- Downward
- Colour consistency (SDCM)
- SDCM=2
- Driver position
- losliggend met plug & play aansluiting
- Flicker
- < 3%
- Primary connections
- GST 18i3, GST18i5pb, Europlug, op driver, On request
- Packaging
- Bulkverpakking
- Product warranty
- 5 Jaar
